Stainless Steel 415 Sheet
AISI 415 Sheet
High Strength Ferritic Grade · Excellent Toughness & Wear Resistance · Thermal Stability · Global Supply
ASTM A240 / ASME SA240
UNS S41500
EN 1.4313
JIS SUS F6NM
📋 Table of Contents
HRS Ferritic · SS 415 Sheet Supplier & Stockist
Introduction to
SS 415 Sheet / AISI 415 Sheet
HRS Ferritic delivers premium ferritic steel and alloy steel solutions for diverse industries. We are recognized as the finest SS 415 Sheet Supplier, SS 415 / AISI Sheet Stockist, and also the best Stainless Steel 415 Sheet Importer. All materials are sourced from trusted ISO, ASTM and ASME-approved manufacturers to ensure consistent quality and value.
- High yield and tensile strength
- Excellent fatigue resistance
- Weldability improved with right procedures
- Long service life under mechanical stresses
- Good machinability and moderate corrosion resistance
- Ideal for structural and industrial applications
415AISI Grade
Grade Overview
SS 415 Sheet / AISI 415 Sheet
SS 415 is a medium carbon alloy steel sheet known for its excellent toughness, strength and wear resistance. A member of the AISI 400 Series, it is used where durability, thermal resistance and mechanical stability are important, offering good machinability and moderate corrosion resistance.
620–750
Tensile Strength MPa
350–450
Yield Strength MPa
18–22%
Elongation
0.5–100
Thickness Range mm
Composition Analysis
Metallurgical Characteristics of SS 415 Sheet
Each element in SS 415 plays a precise role in delivering exceptional strength, toughness and thermal performance.
Fe
Iron
Base element forming the primary structure of the alloy.
Cr
Chromium
Provides corrosion resistance and improves oxidation resistance.
C
Carbon
Increases hardness and strength; supports heat treatment response.
Mn
Manganese
Improves toughness and enhances hot working properties.
Si
Silicon
Increases strength and improves resistance to oxidation.
P
Phosphorus
Residual element that can increase strength but may reduce ductility.
S
Sulfur
Enhances machinability but can lower toughness if present in higher amounts.
Technical Data
Specifications — SS 415 Sheet / AISI 415 Sheet
ASTM A240 · ASME SA240 · UNS S41500
| Specification | Details |
|---|---|
| ASTM / ASME | ASTM A240 / ASME SA240 (Plate, Sheet, and Strip) |
| UNS | UNS S41500 |
| EN | EN 1.4313 |
| DIN | 1.4313 |
| ISO | ISO X3CrNiMo13-4 type |
| JIS | SUS F6NM |
| Product Form | Sheets / Plates |
| Thickness Range | 0.5 mm to 100 mm |
| Standard Widths | 1000 mm, 1219 mm, 1250 mm, 1500 mm, 1800 mm, 2000 mm, 2500 mm, 3000 mm, 3500 mm, etc |
| Standard Lengths | 2000 mm, 2440 mm, 2500 mm, 3000 mm, 5800 mm, 6000 mm, etc |
| Surface Finish | Hot Rolled (HR), Cold Rolled (CR), Annealed & Pickled (AP) |
| Supply Condition | Solution Annealed |
| Cutting Methods | Plasma, Laser, Waterjet, Oxy Propane |
| Packaging | Bundled, Wooden Plates, Bubble Wrap, Customized |
Inventory
Available Stock & Product Forms
Sheets
High-quality flat sheet products in various thicknesses for industrial applications.
Pipes
Seamless and welded pipes for high-temperature and corrosion-resistant use.
M. IPA
Modified Austenitic & Ferritic SS with excellent mechanical properties.
Coils & Strips
Precision-rolled coils and strips for specialized forming operations.
Carbon (C)
0.12 – 0.18% — Controls hardness and supports heat treatment response.
Manganese (Mn)
0.60 – 0.90% — Improves toughness and hot working properties.
Silicon (Si)
≤ 0.40% — Increases strength and oxidation resistance.
Phosphorus (P)
≤ 0.035% — Residual element; controlled for ductility.
Tensile Strength
620–750 MPa — Exceptional for demanding structural applications.
Yield Strength
350–450 MPa — Consistent properties for forming operations.
Elongation
18–22% — Excellent ductility for fabrication.
Hardness
180–220 HB — Consistent machinability and surface quality.
Product Range
Types of SS 415 Sheet / AISI 415 Sheet
Choose from a wide range of finishes based on your application and precision requirements.
Hot Rolled SS 415 Sheet
Cold Rolled SS 415 Sheet
SS 415 Sheet, Annealed
Pickled & Oiled SS 415 Sheet
Custom Cut SS 415 Sheet
Application Sectors
Industries We Serve
Sugar Industry
Global cane and beet processing requiring thermal endurance.
Power Industry
Electricity generation and distribution systems.
Ship Building
Marine propulsion and exhaust components.
Mechanical & Plant Engineering
Industrial machinery design solutions.
Food, Beverage & Dairy
Processed food manufacturing environments.
Oil & Gas Plant
Refinery furnace units and burner assemblies.
Chemical Composition
Chemical Properties of SS 415 Sheet / AISI 415 Sheet
The controlled carbon content in SS 415 provides a balance between hardness, ductility and heat treatment response.
| Element | Percentage (%) |
|---|---|
| Carbon (C) | 0.12 – 0.18 |
| Manganese (Mn) | 0.60 – 0.90 |
| Silicon (Si) | ≤ 0.40 |
| Phosphorus (P) | ≤ 0.035 |
| Sulfur (S) | ≤ 0.040 |
Performance Data
Mechanical Properties of SS 415 Sheet / AISI 415 Sheet
620–750
Tensile Strength
MPa — Exceptional for demanding structural applications
350–450
Yield Strength
MPa — Ideal for forming and fabrication
18–22%
Elongation
Excellent ductility for cold-forming
180–220
Hardness
HB — Ensures machinability
High
Impact Strength
Resistant to sudden fracture or deformation
Cost Information
Price List of SS 415 Sheet / AISI 415 Sheet
Price Factors
What affects the price?
- Cost of raw materials fluctuation
- Dimensions and thickness of sheets
- Manufacturing requirements
- Quantity and logistics
Get Pricing Today
Get A Quote!
Competitive pricing · Fast replies · Export-ready packaging
📧 [email protected]
International Standards
Equivalent Grades for SS 415 Sheet / AISI 415 Sheet
SS 415 is recognized across all major global standards with equivalent metallurgical designations.
| Standard / System | Equivalent Grade / Designation |
|---|---|
| ASTM / ASME (USA) | AISI 415 (often designated F6NM) |
| UNS | UNS S41500 |
| DIN (German / EN) | 1.4313 (also EN X3CrNiMo13-4) |
| JIS (Japanese) | SUS F6NM |
| BS (British) | 425C11 |
| AFNOR (French) | Z6CND13-04 |
| GOST (Russia) | 03X13H4M |
| SS (Swedish) | SS 2385 |
| GB (China) | S41595 or 04Cr13Ni5Mo |
| ISO (International) | X3CrNiMo13-4 type |
📦
Ready Stock & Product Forms
- Flat Products: Precision sheets, heavy plates, shim sheets
- Coils & Strips: Slitting coils, perforated coils, thin foils from 0.05 mm
- Speciality Forms: Circles, rings, custom-cut blanks, chequered (tread) plates
- Edge Conditions: Mill edge, slit edge, round edge, square edge
🏭
Quality Assurance & Logistics
- Testing: PMI, Ultrasonic Testing (UT), Radiography (RT), corrosion testing
- Certification: EN 10204 3.1 / 3.2, NACE compliance (on request)
- Global Supply: USA, UAE, Saudi Arabia, Singapore, Indonesia, Europe
- Export Packaging: ISPM-15 fumigated wooden crates, shrink-wrapped & moisture-protected
Use Cases
Applications and Importance of SS 415 Sheet / AISI Sheet
🌾 Fertilizer Industry
Used for reactor shells, pressure vessel claddings, storage tank panels and structural supports.
🧪 Chemical Processing
Used in housings for equipment, mixer blades and structural linings.
✈️ Aerospace
Used in non-flight critical structural components, mounting plates, reinforcement plates and fatigue-resistant support assemblies.
⛽ Oil & Gas
Used for pipeline supports, valve bodies, flanges, drilling rig structural parts and equipment base plates.
💊 Pharmaceuticals
Used for machinery frames, processing equipment casings and storage racks requiring dimensional stability.
🏗️ Construction & Infrastructure
Used in bridge components, beams and columns, gusset plates and heavy-duty structural frames.
⚡ Electric Sector & EV Batteries
Used in battery enclosures, protective casings, structural frameworks and support panels.
🚗 Automotive
Widely used in chassis reinforcements and transmission housings.
Why HRS Ferritic
Why Choose HRS Ferritic for SS 415 Sheet / AISI 415 Sheet?
HRS Ferritic delivers premium-quality SS 415 Sheet / AISI 415 Sheet, which exceeds international standards. Contact us today to receive expert advice and the best prices on SS 415 sheets from a global supplier you can trust.
Trusted SS 415 Sheet Supplier & Stockist
Materials that are ISO & ASTM Certified
Source globally from valued and approved mills
Bulk availability & competitive pricing
Fast delivery and custom cutting
Complete documentation & test certificates
Expert advice and post-sales services
Supply to 20+ countries worldwide
🇮🇳
Cities We Supply In India
New Delhi · Ahmedabad · Jaipur · Surat · Salem · Gandhinagar · Varanasi · Haldia ·
Bhiwandi · Tiruppur · Jamnagar · Thiruvananthapuram · Rajahmundry · Visakhapatnam · Bhubaneswar ·
Vijaywada · Rajkot · Bharuch · Coimbatore · Nagpur · Raipur · Cochin · Ludhiana · Panipat · Durgapur ·
Agra · Indore · Kuala Lumpur · Al Jubail · Pimpri-Chinchwad · Sharjah · Karachi · Chandigarh · Bogota · Muscat · Madrid · Tehran · Granada · Jakarta · Los Angeles · Rio de Janeiro · Melbourne · Cairo · New York · Busan · Milan · Montreal · Singapore · Sydney · Dubai · Lagos · Gurgaon · Port-of-Spain · Hong Kong · Navi Mumbai · Secunderabad · Bangkok · Aberdeen · Bhopal · Atyrau · Caracas · Jamshedpur · Thane · Faridabad · Ahvaz · Ahmedabad · Hanoi · Bengaluru · Dallas · Moscow · Surat · Riyadh · Rajkot · Al Khobar · Hyderabad · Haryana · Ernakulam · Gimhae-si · Algiers · Thiruvananthapuram · Brisbane · Calgary · Mumbai · Chennai · Courbevoie · Toronto · Vung Tau · Ankara · Doha · Nagpur · Howrah · Ranchi · Perth · Noida · Houston · Kolkata · Chiyoda · Mexico City · Edmonton. Geoje-si · Abu Dhabi · Santiago · New Delhi · Colombo · Ludhiana · Lahore · Coimbatore · Ho Chi Minh City · Manama · Ulsan · London · Visakhapatnam · Jaipur · Kuwait City · Seoul · Istanbul · Pune · Baroda · Kanpur · La Victoria · Jeddah · Dammam · Petaling Jaya · Nashik · Vadodara ·jamnagar ·hazira · jubail industrial city · Ajman · Capetown · San Francisco · sao paulo · Barcelona · Ahmedi · Muscat · Madrid · Birmingham · Johannesburg.
🌍
Countries We Export To
Saudi Arabia · Qatar · Canada · Sri Lanka · Iran · Nigeria · Bangladesh · Oman · UAE ·
Turkey · Kuwait · Venezuela · Africa · Singapore · Netherlands · United Kingdom · Mexico · Malaysia ·
United States · Australia · Japan Saudi Arabia · Iran · Iraq · UAE · Qatar · Bahrain · Oman · Kuwait · Turkey · Yemen · Syria · Jordan · Cyprus · Nigeria · Algeria · Angola · South Africa · Libya · Egypt · Sudan · Equatorial Guinea · The Republic Of Congo · Gabon · USA · Canada · Mexico · Panama · Costa Rica · Puerto Rica · Trinidad And Tobago · Jamaica · Bahamas · Denmark · Russia · Norway · Germany · France · Italy · Uk · Spain · Ukraine · Netherland · Belgium · Greece · Czech Republic · Portugal · Hungary · Albania · Austria · Switzerland · Slovakia · Finland · Ireland · Croatia · Slovenia · Malta · India · Singapore · Malaysia · Indonesia · Thailand · Vietnam · South Korea · Japan · Sri Lanka · Maldives · Bangladesh · Myanmar · Taiwan · Cambodia · Argentina · Bolivia · Brazil · Chile · Venezuela · Colombia · Ecuador · Guyana · Paraguay · Uruguay · New Zealand · Romania · Puerto Rico · Nepal · Kenya · Afghanistan · Lithuania · Belarus · Zimbabwe · Israel · Azerbaijan · Poland · Australia · Morocco · Philippines.
Support
Frequently Asked Questions
Quick answers to common queries about SS 415 Sheet / AISI 415 Sheet.
SS 415 is a martensitic stainless steel sheet with good corrosion resistance, high strength, and excellent hardness. It is often used in industrial and structural applications.
Common uses include pump shafts, valve components, fasteners, industrial machinery, and marine applications.
Yes, it is weldable, but preheating and post-weld heat treatment may be required to prevent cracking due to its higher carbon content.
SS 415 has higher strength and hardness than 410/410S and often contains slightly different alloying elements for improved corrosion resistance in harsher environments.
Yes, SS 415 can be heat-treated (tempered or hardened) to increase hardness and mechanical strength for demanding applications.
