Stainless Steel 409-75 Sheet
AISI 409-75 Plate
Ferritic Chromium Alloy Grade · Good Oxidation Resistance · Moderate Corrosion Resistance · Exceptional Weldability · Global Supply
ASTM A240 / AISI 409-75
UNS S40900
EN 1.4512
JIS SUH 409
📋 Table of Contents
HRS Ferritic · SS 409-75 Plate Supplier & Stockist
Introduction to
Stainless Steel 409-75 Plates
HRS Ferritic is a well-known name in the industry of stainless steel and is a trusted SS 409-75 Plate Supplier, Stainless Steel 409-75 Plate Importer, and AISI 409-75 Plate Stockist. We are committed to providing high-quality ferritic stainless steel products from highly valued mills that are certified worldwide. With a solid supply chain, technological expertise and a customer-first focus, we cater to various industries like oil and gas, automotive, chemical processing, and infrastructure. Our plates are produced according to international standards, which ensures the highest quality, durability and consistent performance.
- Good oxidation resistance and moderate corrosion resistance
- Exceptional weldability
- Cost-effective alternative to austenitic grades
- Strength and high temperature oxidation resistance
- Magnetic properties with thermal stability
- Ease of fabrication
409Ferritic Grade
Grade Overview
Introduction & Overview — Stainless Steel 409-75 Plates
The SS409-75 Plate, also referred to as AISI 409 75 plate, is a ferritic steel plate that is primarily made of chromium alloy. It offers good oxidation resistance, moderate resistance to corrosion and exceptional weldability. This grade is commonly used in situations where strength, cost efficiency and resistance to high temperature oxidation are needed. The basic principle of SS 409-75 Plate is founded on its ferritic structure that provides stability under heat stress as well as resistance to scaling at high temperatures. The chromium content forms an oxide protective layer on the surface, delaying further oxidation and increasing the life of the product.
10.5–11.75%
Chromium Content
Ferritic
Structure
380–480
Tensile Strength MPa
0.5–100
Thickness Range mm
Composition Analysis
Metallurgical Properties of SS 409-75 Plate
Each element in SS 409-75 plays a precise role in delivering good oxidation resistance, weldability and mechanical strength.
Cr
Chromium
Provides corrosion resistance and improves oxidation resistance.
Ni
Nickel
Enhances corrosion resistance and toughness at elevated temperatures.
C
Carbon
Contributes to strength and hardness, but too much can reduce corrosion resistance.
Mn
Manganese
Improves tensile strength and hardness; helps in deoxidation during manufacturing.
Si
Silicon
Adds oxidation resistance and improves strength at high temperatures.
P
Phosphorus
Usually a residual element; affects strength and machinability.
S
Sulfur
Improves machinability but may slightly reduce corrosion resistance.
Fe
Iron
Base metal forming the matrix of the stainless steel.
Technical Data
Specifications for Stainless Steel 409-75 Plate
ASTM A240 / AISI 409-75 · UNS S40900 · EN 1.4512 · JIS SUH 409
| Specification | Details |
|---|---|
| ASTM / AISI | ASTM A240 / AISI 409-75 (Plate, Sheet, and Strip) |
| UNS | UNS S40900 |
| EN | EN 1.4512 |
| DIN | 1.4512 |
| ISO | ISO X2CrTi12 |
| JIS | SUH 409 |
| Product Form | Plates / Sheets |
| Thickness Range | 0.5 mm to 100 mm |
| Standard Widths | 1000 mm, 1219 mm, 1250 mm, 1500 mm, 1800 mm, 2000 mm, 2500 mm, 3000 mm, 3500 mm, etc |
| Standard Lengths | 2000 mm, 2440 mm, 2500 mm, 3000 mm, 5800 mm, 6000 mm, etc |
| Custom Width Cut | Available as per customer requirement |
| Custom Length Cut | Available as per customer requirement |
| Surface Finish | Hot Rolled (HR), Cold Rolled (CR), Annealed & Pickled (AP) |
| Supply Condition | Solution Annealed |
| Cutting Methods | Plasma, Laser, Waterjet, Oxy Propane |
| Packaging | Bundled, Wooden Plates, Bubble Wraps, Customized |
Inventory
Available Stock & Product Forms
Plates
High-quality flat plate products in various thicknesses for industrial applications.
Pipes
Seamless and welded pipes for high-temperature and corrosion-resistant use.
M. IPA
Modified Austenitic & Ferritic SS with excellent mechanical properties.
Coils & Strips
Precision-rolled coils and strips for specialized forming operations.
Chromium (Cr)
10.5 – 11.75% — Provides corrosion and oxidation resistance.
Carbon (C)
≤ 0.08% — Low level ensures weldability and corrosion resistance.
Manganese (Mn)
≤ 1.0% — Improves tensile strength and hardness.
Silicon (Si)
≤ 1.0% — Adds oxidation resistance and improves high-temperature strength.
Tensile Strength
380–480 MPa — Suitable for demanding structural applications.
Yield Strength
≥ 170 MPa — Consistent properties for forming operations.
Elongation
≥ 20% — Excellent ductility for cold-forming and fabrication.
Hardness
≤ 183 HB — Consistent machinability and surface quality.
Product Range
Different Types of SS 409-75 Plate / AISI 409-75 Plate
Choose from a wide range of finishes based on your application and precision requirements.
Hot-rolled SS 409-75 Plate
Cold-rolled SS 409-75 Plate
Annexed SS 409-75 Plate
Affixed SS 409-75 Plate
Customized Cut-to-Size Plates
Application Sectors
Industries We Serve
Sugar Industry
Global cane and beet processing requiring thermal endurance.
Power Industry
Electricity generation and distribution systems.
Ship Building
Marine propulsion and exhaust components.
Mechanical & Plant Engineering
Industrial machinery design solutions.
Food, Beverage & Dairy
Processed food manufacturing environments.
Oil & Gas Plant
Refinery furnace units and burner assemblies.
Chemical Composition
Chemical Property of SS 409-75 Plate / AISI 409-75 Plate
The chromium content in SS 409-75 forms an oxide protective layer on the surface, delaying further oxidation and increasing the life of the product in high-temperature industrial environments.
| Element | Percentage (%) |
|---|---|
| Carbon (C) | ≤ 0.08 |
| Chromium (Cr) | 10.5 – 11.75 |
| Manganese (Mn) | ≤ 1.0 |
| Silicon (Si) | ≤ 1.0 |
| Phosphorus (P) | ≤ 0.04 |
| Sulfur (S) | ≤ 0.03 |
Performance Data
Mechanical Properties of Stainless Steel 409-75 Plate (AISI)
380–480
Tensile Strength
MPa — Suitable for demanding structural applications
≥ 170
Yield Strength
MPa — Ideal for forming and fabrication
≥ 20%
Elongation
Excellent ductility for cold-forming and fabrication
≤ 183 HB
Hardness
Maximum — Ensures machinability
Cost Information
Price List for SS 409-75 Plate / AISI 409-75 Plate
Price Factors
Factors that Influence the Price
- Variations in the cost of raw material
- The thickness of the plate and its size
- Production procedure (hot or cold rolling)
- Customs duties, logistics and import
- Order quantity
International Standards
Equivalent Grades to SS 409-75 Plate / AISI 409-75 Plate
SS 409-75 is recognized across all major global standards with equivalent metallurgical designations.
| Standard | Equivalent Grade / Designation |
|---|---|
| AISI (USA) | 409 |
| UNS (USA) | S40900 |
| ASTM | ASTM A240 TP409 / ASME SA240 TP409 |
| EN (Europe) | 1.4512 |
| DIN (Germany) | X2CrTi12 |
| BS (UK) | 409 S 19 |
| JIS (Japan) | SUH 409 |
| AFNOR (France) | Z3CT12 |
| GOST (Russia) | Equivalent often listed as 08Х13 (but not official) |
| GB / China | 06Cr11Ti (commercial reference) |
| ISO | X2CrTi12 (same numeric used under ISO/EN grouping) |
| UNI (Italy) | X2CrTi12 (follows the EN numeric system) |
| SS (Sweden) | Often referenced via EN numeric 1.4512 |
| KS (Korea) | SUH 409 (aligned with JIS naming) |
| IS (India) | SS 409 / AISI 409 (commonly specified as ASTM/EN standard in India) |
📦
Ready Stock & Product Forms
- Flat Products: Precision sheets, heavy plates, shim sheets
- Coils & Strips: Slitting coils, perforated coils, thin foils from 0.05 mm
- Speciality Forms: Circles, rings, custom-cut blanks, chequered (tread) plates
- Edge Conditions: Mill edge, slit edge, round edge, square edge
🏭
Quality Assurance & Logistics
- Testing: PMI, Ultrasonic Testing (UT), Radiography (RT), corrosion testing
- Certification: EN 10204 3.1 / 3.2, NACE compliance (on request)
- Global Supply: USA, UAE, Saudi Arabia, Singapore, Indonesia, Europe
- Export Packaging: ISPM-15 fumigated wooden crates, shrink-wrapped & moisture-protected
Use Cases
Applications & Importance of SS 409-75 Plate (AISI)
🌾 Fertilizer Industry
Utilized for ammonia-handling systems and storage tanks for urea, along with ducting and heat exchanger cables where oxidation resistance and thermal stability is essential in cyclic heating conditions.
🧪 Chemical Processing
Used in reactor vessel shells, condenser housings, pipeline supports, and furnace linings subjected to moderate temperature and corrosion that benefit from good weldability and structural stability.
✈️ Aerospace
Utilized for engine exhaust shrouds, thermal shields, brackets and non-load-bearing structural parts where heat resistance and dimensional stability under thermal cycling is crucial.
⛽ Oil & Gas
In exhaust stacks, flare systems, compressor housings, equipment skids, and insulation jacketing because of its resistance to heat, scaling and atmospheric exposure.
💊 Pharmaceuticals
Used in equipment enclosures, HVAC duct panels, cleanroom support structures, and non-contact surfaces for longevity, cleanliness, and oxidation resistance.
🏗️ Construction & Infrastructure
Used for bridge expansion joints, structural façades, roofing, cladding and noise-proofing, providing durability and long-term weather protection.
⚡ Electric Sector & EV Batteries
Used in battery enclosures, power distribution cabinets, thermal shields and grounding frames because of its magnetic properties and efficient heat management.
🚗 Automotive
Widely utilized in exhaust manifolds, catalytic converter housings, heat shields, mufflers and emission control parts requiring high-temperature oxidation resistance and weldability.
Why HRS Ferritic
Why Should You Choose HRS Ferritic SS 409-75 Plate / AISI 409-75 Plate?
HRS Ferritic is a customer-focused stainless steel firm that specializes in ferritic-grade stainless steel. With over a decade of experience in the field, we provide high-quality materials that are in line with international standards and meet specific requirements for projects. Contact HRS today for high-quality SS 409-75 plates you can count on.
Trusted SS 409-75 Plate / AISI 409-75 Plate Supplier & Stockist
Global sourcing from mills that have been certified
Quick delivery and stock availability
Competitive pricing
Quality assurance strict
Custom-designed solutions
Complete mill test certificates
Supply to 20+ countries worldwide
🇮🇳
Cities We Supply In India
New Delhi · Ahmedabad · Jaipur · Surat · Salem · Gandhinagar · Varanasi · Haldia ·
Bhiwandi · Tiruppur · Jamnagar · Thiruvananthapuram · Rajahmundry · Visakhapatnam · Bhubaneswar ·
Vijaywada · Rajkot · Bharuch · Coimbatore · Nagpur · Raipur · Cochin · Ludhiana · Panipat · Durgapur ·
Agra · Indore · Kuala Lumpur · Al Jubail · Pimpri-Chinchwad · Sharjah · Karachi · Chandigarh · Bogota · Muscat · Madrid · Tehran · Granada · Jakarta · Los Angeles · Rio de Janeiro · Melbourne · Cairo · New York · Busan · Milan · Montreal · Singapore · Sydney · Dubai · Lagos · Gurgaon · Port-of-Spain · Hong Kong · Navi Mumbai · Secunderabad · Bangkok · Aberdeen · Bhopal · Atyrau · Caracas · Jamshedpur · Thane · Faridabad · Ahvaz · Ahmedabad · Hanoi · Bengaluru · Dallas · Moscow · Surat · Riyadh · Rajkot · Al Khobar · Hyderabad · Haryana · Ernakulam · Gimhae-si · Algiers · Thiruvananthapuram · Brisbane · Calgary · Mumbai · Chennai · Courbevoie · Toronto · Vung Tau · Ankara · Doha · Nagpur · Howrah · Ranchi · Perth · Noida · Houston · Kolkata · Chiyoda · Mexico City · Edmonton. Geoje-si · Abu Dhabi · Santiago · New Delhi · Colombo · Ludhiana · Lahore · Coimbatore · Ho Chi Minh City · Manama · Ulsan · London · Visakhapatnam · Jaipur · Kuwait City · Seoul · Istanbul · Pune · Baroda · Kanpur · La Victoria · Jeddah · Dammam · Petaling Jaya · Nashik · Vadodara ·jamnagar ·hazira · jubail industrial city · Ajman · Capetown · San Francisco · sao paulo · Barcelona · Ahmedi · Muscat · Madrid · Birmingham · Johannesburg.
🌍
Countries We Export To
Saudi Arabia · Qatar · Canada · Sri Lanka · Iran · Nigeria · Bangladesh · Oman · UAE ·
Turkey · Kuwait · Venezuela · Africa · Singapore · Netherlands · United Kingdom · Mexico · Malaysia ·
United States · Australia · Japan Saudi Arabia · Iran · Iraq · UAE · Qatar · Bahrain · Oman · Kuwait · Turkey · Yemen · Syria · Jordan · Cyprus · Nigeria · Algeria · Angola · South Africa · Libya · Egypt · Sudan · Equatorial Guinea · The Republic Of Congo · Gabon · USA · Canada · Mexico · Panama · Costa Rica · Puerto Rica · Trinidad And Tobago · Jamaica · Bahamas · Denmark · Russia · Norway · Germany · France · Italy · Uk · Spain · Ukraine · Netherland · Belgium · Greece · Czech Republic · Portugal · Hungary · Albania · Austria · Switzerland · Slovakia · Finland · Ireland · Croatia · Slovenia · Malta · India · Singapore · Malaysia · Indonesia · Thailand · Vietnam · South Korea · Japan · Sri Lanka · Maldives · Bangladesh · Myanmar · Taiwan · Cambodia · Argentina · Bolivia · Brazil · Chile · Venezuela · Colombia · Ecuador · Guyana · Paraguay · Uruguay · New Zealand · Romania · Puerto Rico · Nepal · Kenya · Afghanistan · Lithuania · Belarus · Zimbabwe · Israel · Azerbaijan · Poland · Australia · Morocco · Philippines.
Support
Frequently Asked Questions
Quick answers to common queries about SS 409-75 Plate / AISI 409-75 Plate.
SS 409-75 plates are ferritic stainless steel plates stabilized with titanium, offering good corrosion resistance and improved mechanical strength at elevated temperatures.
SS 409-75 plates are widely used in automotive exhaust systems, heat exchangers, boiler components, agricultural equipment, and structural parts exposed to mild corrosive environments.
SS 409-75 provides enhanced tensile strength (75 ksi minimum) compared to standard 409 grade, making it suitable for higher load-bearing and high-temperature applications.
Equivalent grades of SS 409-75 include UNS S40975, EN 1.4512, and ASTM A240 Type 409 (with 75 ksi tensile strength requirement).
Yes, SS 409-75 plates perform well in temperatures up to approximately 675°C, making them suitable for exhaust manifolds, flue gas systems, and thermal processing equipment.
